Product Datasheet Search Results:
7 Pages, 335 KB, Original- TIP47TU
- Aptina Imaging
- Trans GP BJT NPN 250V 1A 2000mW 3-Pin(3+Tab) TO-220 Tube
Product Details Search Results:
Fairchildsemi.com/TIP47TU
{"Category":"Discrete Semiconductor Products","Current - Collector (Ic) (Max)":"1A","DC Current Gain (hFE) (Min) @ Ic, Vce":"30 @ 300mA, 10V","Transistor Type":"NPN","Product Photos":"TO-220-3","Family":"Transistors (BJT) - Single","Vce Saturation (Max) @ Ib, Ic":"1V @ 200mA, 1A","Series":"-","Standard Package":"50","Supplier Device Package":"TO-220","PCN Design/Specification":"Lead Frame Dimensions 29/Nov/2007 Heatsink Desing Changes 24/Feb/2014","Packaging":"Tube","Datasheets":"TIP47-50 TO220B03 Pkg Drawi...
1846 Bytes - 07:22:51, 22 March 2025
Onsemi.com/TIP47TU
{"Collector Current (DC) ":"1(A)","Transistor Polarity":"NPN","Power Dissipation":"2(W)","Mounting":"Through Hole","Emitter-Base Voltage":"5(V)","Category ":"Bipolar Power","Packaging":"Rail/Tube","Operating Temperature Classification":"Military","Rad Hardened":"No","Frequency":"10(MHz)","Package Type":"TO-220","Collector-Base Voltage":"350(V)","DC Current Gain":"30","Operating Temp Range":"-65C to 150C","Output Power":"Not Required(W)","Configuration":"Single","Pin Count":"3 +Tab","Number of Elements":"1"}...
1556 Bytes - 07:22:51, 22 March 2025
