{"Category":"Circuit Protection","Voltage - Clamping (Max) @ Ipp":"-","Catalog Drawings":"SMAJ,SMBJ Series SMBJ Series Footprint","Operating Temperature":"-55\u00b0C ~ 150\u00b0C (TJ)","Featured Product":"SMAJ/SMBJ/SMCJ/SMLJ Discrete TVS Diodes","Package / Case":"DO-214AA, SMB","Type":"Zener","Product Photos":"LSPXXXXBJR-S","Voltage - Breakdown (Min)":"50V","Applications":"General Purpose","Datasheets":"SMBJ Series","Standard Package":"1","Voltage - Reverse Standoff (Typ)":"45V","RoHS Information":"SMBJ Ser...

{"Status":"ACTIVE","Polarity":"UNIDIRECTIONAL","Terminal Finish":"TIN LEAD","Package Body Material":"PLASTIC/EPOXY","Mfr Package Description":"ROHS COMPLIANT, PLASTIC, CASE SMB, 2 PIN","Breakdown Voltage-Min":"50 V","Terminal Form":"C BEND","Non-rep Peak Rev Power Dis-Max":"600 W","Package Style":"SMALL OUTLINE","Breakdown Voltage-Max":"57.5 V","Diode Element Material":"SILICON","Power Dissipation Limit-Max":"5 W","Number of Elements":"1","Stand-off Voltage":"45 V","Terminal Position":"DUAL","Diode Type":"T...

{"Category":"Circuit Protection","Voltage - Clamping (Max) @ Ipp":"72.7V","Catalog Drawings":"SMBJ Series Side SMBJ Series Top","Operating Temperature":"-55\u00b0C ~ 150\u00b0C (TJ)","Package / Case":"DO-214AA, SMB","Type":"Zener","Product Photos":"DO-214AA SMB","Voltage - Breakdown (Min)":"50V","Applications":"General Purpose","Datasheets":"SMBJ5.0A, CA - SMBJ170A, CA","Standard Package":"3,000","Voltage - Reverse Standoff (Typ)":"45V","Unidirectional Channels":"1","Bidirectional Channels":"-","Current - P...

{"Category":"Circuit Protection","Voltage - Clamping (Max) @ Ipp":"72.7V","Catalog Drawings":"SMBJ Series Side SMBJ Series Top","Operating Temperature":"-55\u00b0C ~ 150\u00b0C (TJ)","Package / Case":"DO-214AA, SMB","Type":"Zener","Product Photos":"DO-214AA SMB","Voltage - Breakdown (Min)":"50V","Applications":"General Purpose","Datasheets":"SMBJ5.0A, CA - SMBJ170A, CA","Standard Package":"3,000","Voltage - Reverse Standoff (Typ)":"45V","RoHS Information":"RoHS Cert of Compliance","Power Line Protection":"N...

{"Status":"DISCONTINUED","Polarity":"UNIDIRECTIONAL","Terminal Finish":"TIN LEAD","Package Body Material":"PLASTIC/EPOXY","Mfr Package Description":"PLASTIC, SMB, 2 PIN","Breakdown Voltage-Min":"50 V","Terminal Form":"C BEND","Non-rep Peak Rev Power Dis-Max":"600 W","Package Style":"SMALL OUTLINE","Breakdown Voltage-Max":"57.5 V","Diode Element Material":"SILICON","Number of Elements":"1","Stand-off Voltage":"45 V","Terminal Position":"DUAL","Diode Type":"TRANS VOLTAGE SUPPRESSOR DIODE","Package Shape":"REC...

{"Status":"ACTIVE","Polarity":"UNIDIRECTIONAL","Package Body Material":"PLASTIC/EPOXY","Mfr Package Description":"ROHS COMPLIANT, PLASTIC, SMB, 2 PIN","Breakdown Voltage-Min":"50 V","Terminal Form":"C BEND","Non-rep Peak Rev Power Dis-Max":"600 W","Package Style":"SMALL OUTLINE","Breakdown Voltage-Max":"55.5 V","Diode Element Material":"SILICON","Power Dissipation Limit-Max":"5 W","Number of Elements":"1","Stand-off Voltage":"45 V","Terminal Position":"DUAL","Diode Type":"TRANS VOLTAGE SUPPRESSOR DIODE","Pa...

{"Category":"Circuit Protection","Voltage - Clamping (Max) @ Ipp":"72.7V","Operating Temperature":"-55\u00b0C ~ 150\u00b0C (TJ)","Package / Case":"DO-214AA, SMB","Type":"Zener","Product Photos":"DO-214AA","Voltage - Breakdown (Min)":"50V","Applications":"General Purpose","Datasheets":"SMBJ5V0-170(C)A DO214AA Pkg Drawing","Standard Package":"1","Voltage - Reverse Standoff (Typ)":"45V","Unidirectional Channels":"1","Bidirectional Channels":"-","Current - Peak Pulse (10/1000\u00b5s)":"8.3A","Online Catalog":"S...

{"Polarity":"UNIDIRECTIONAL","Terminal Finish":"NOT SPECIFIED","Breakdown Voltage-Min":"50 V","Terminal Form":"C BEND","Breakdown Voltage-Max":"55.3 V","Package Shape":"RECTANGULAR","Status":"ACTIVE","Lead Free":"Yes","Package Body Material":"PLASTIC/EPOXY","Non-rep Peak Rev Power Dis-Max":"600 W","EU RoHS Compliant":"Yes","Configuration":"SINGLE","Stand-off Voltage":"45 V","Power Dissipation Limit-Max":"1.5 W","Surface Mount":"Yes","Mfr Package Description":"PLASTIC, SMB, 2 PIN","Number of Terminals":"2","...

{"Category":"Circuit Protection","Voltage - Clamping (Max) @ Ipp":"72.7V","Catalog Drawings":"SMBJ, P6SMB, P6SMBJ Series SMBJ, P6SMB, P6SMBJ Series Footprint","Operating Temperature":"-55\u00b0C ~ 150\u00b0C (TJ)","Featured Product":"Littelfuse and Digi-Key offer kits for popular TVS SMD diodes","Voltage - Breakdown (Min)":"50V","Package / Case":"DO-214AA, SMB","Type":"Zener","Product Photos":"DO-214AA, SMB","Product Training Modules":"Transient Voltage Suppression (TVS) Diodes","Applications":"General Purp...

{"Polarity":"Unidirectional","Termination Style":"SMD/SMT","Width":"3.94 mm","Package / Case":"DO-214AA","Type":"Transient Voltage Suppressors","Packaging":"Reel","Product Category":"TVS Diodes - Transient Voltage Suppressors","Brand":"Littelfuse","Unit Weight":"0.003280 oz","Maximum Operating Temperature":"+ 150 C","Manufacturer":"Littelfuse","Clamping Voltage":"72.7 V","Operating Temperature Range":"- 55 C to + 150 C","Length":"4.57 mm","RoHS":"Details","Series":"SMBJ-HR","Height":"2.44 mm","Mounting Styl...

{"Polarity":"Unidirectional","Termination Style":"SMD/SMT","Width":"3.94 mm","Package / Case":"DO-214AA","Type":"Transient Voltage Suppressors","Packaging":"Reel","Product Category":"TVS Diodes - Transient Voltage Suppressors","Brand":"Littelfuse","Unit Weight":"0.003280 oz","Maximum Operating Temperature":"+ 150 C","Manufacturer":"Littelfuse","Clamping Voltage":"72.7 V","Operating Temperature Range":"- 55 C to + 150 C","Length":"4.57 mm","RoHS":"Details","Series":"SMBJ-HRA","Height":"2.44 mm","Mounting Sty...
