{"Connector Shell Size:":"8","Connector Mounting:":"Cable","Contact Termination:":"Solder","Contact Material:":"Copper","Contact Plating:":"Gold","Contact Gender:":"Pin","Product Range:":"MIL-C-26482 Series I","Gender:":"Plug","No. of Contacts:":"2","Connector Type:":"Circular Military","Connector Body Material:":"Aluminium","Insert Arrangement:":"8-2","Contact Termination Type:":"Solder","SVHC:":"To Be Advised"}...

{"Status":"ACTIVE","Body/Shell Style":"PLUG","MIL Conformance":"Yes","Option":"GENERAL PURPOSE","Mounting Type":"CABLE","Environmental Characteristics":"ENVIRONMENT RESISTANT","Backshell Type":"SOLID","Shell Finish":"CADMIUM PLATED","Contact Gender":"MALE","Coupling Type":"BAYONET","Manufacturer Series":"MS3116F","Mating Information":"MULTIPLE MATING PARTS AVAILABLE","Shell Size":"8","Shell Material":"ALUMINUM ALLOY","Termination Type":"SOLDER","Total Number of Contacts":"2","Connection Type":"MIL SERIES CO...

{"Category":"Connectors, Interconnects","Current Rating":"7.5A","Voltage - Rated":"600VAC","Operating Temperature":"-55\u00b0C ~ 125\u00b0C","Shell Size, MIL":"-","Contact Finish Thickness":"-","Number of Positions":"2","Product Training Modules":"26482 Series 1 Miniature Cylindrical Connector Mil-DTL-5015 and AC Threaded Connectors","Datasheets":"MIL-C-26482, Series 1 Catalog","Standard Package":"1","Family":"Circular Connectors","Shell Size - Insert":"8-2","Connector Type":"Plug, Male Pins","Contact Finis...

{"Current Rating (Max)":"7.5(A)","Family":"MS3116","Gender":"PL","Number of Terminals":"2","Body Orientation":"Straight","Contact Gender":"PIN","Mounting Style":"Cable","Number of Ports":"1(Port)","Operating Temp Range":"-55C to 125C","Rad Hardened":"No","Contact Plating":"Gold Over Nickel","Termination Method":"Solder","Shell Size / Insert Arrangement":"8-2","Number of Contacts":"2(POS)","Type":"Circular","Contact Classification":"2Signal","Contact Material":"Copper Alloy"}...

{"Category":"Connectors, Interconnects","Current Rating":"7.5A","Voltage - Rated":"600VAC, 850VDC","Operating Temperature":"-55\u00b0C ~ 125\u00b0C","Shell Size, MIL":"-","Contact Finish Thickness":"50\u00b5in (1.27\u00b5m)","Number of Positions":"2","Datasheets":"MS3116F8-2PW Drawing MS3116F8-2PW Datasheet","Standard Package":"1","Family":"Circular Connectors","Shell Size - Insert":"8-2","Connector Type":"Plug, Male Pins","Contact Finish":"Gold","Fastening Type":"Bayonet Lock","Termination":"Solder Cup","F...

{"Contact Classification":"2Signal","Type":"Circular","Current Rating (Max)":"7.5/Contact(A)","Product Height (mm)":"Not Required(mm)","Contact Plating":"Gold Over Nickel","Termination Method":"Solder","Shell Size / Insert Arrangement":"8-2","Strain Relief":"No","Shell Plating":"Cadmium","Gender":"PL","Body Orientation":"Straight","Contact Gender":"PIN","Number of Ports":"1(Port)","Operating Temp Range":"-55C to 125C","Product Diameter (mm)":"19.05(mm)","Family":"MS3116","Number of Terminals":"2","Mounting ...
