{"Status":"ACTIVE","Body/Shell Style":"RECEPTACLE","MIL Conformance":"Yes","Option":"GENERAL PURPOSE","Mounting Type":"PANEL","Contact Finish - Mating":"SILVER","Shell Finish":"CADMIUM PLATED","Backshell Type":"SOLID","Environmental Characteristics":"CORROSION/ENVIRONMENT RESISTANT","Contact Finish - Termination":"SILVER","Contact Gender":"MALE","Coupling Type":"THREADED","Manufacturer Series":"MS3102E","Mating Information":"MULTIPLE MATING PARTS AVAILABLE","Shell Size":"24","Shell Material":"ALUMINUM ALLOY...

{"Product Category":"Circular MIL Spec Connector","Series":"MS 5015","MIL Type":"MIL-DTL-5015","Contact Gender":"Pin (Male)","Shell Style":"Box Mount","Brand":"Amphenol Industrial","Insert Arrangement":"24-28","Tradename":"5015","Shell Size":"24","Product Type":"Receptacles","Number of Positions":"24 Position","Shell Plating":"Olive Drab Chromate over Cadmium","Manufacturer":"Amphenol"}...

{"Number of Contacts":"24(POS)","Number of Terminals":"24","Current Rating (Max)":"22(A)","Family":"MS","Voltage Rating":"250VDC/200VAC","Gender":"RCP","Body Orientation":"Straight","Contact Gender":"PIN","Mounting Style":"Box","Number of Ports":"1(Port)","Operating Temp Range":"-55C to 125C","Rad Hardened":"No","Contact Plating":"Silver","Termination Method":"Solder","Shell Size / Insert Arrangement":"24-28","Strain Relief":"No","Type":"Circular","Contact Classification":"24Signal","Contact Material":"Copp...

{"Category":"Connectors, Interconnects","Current Rating":"22A","Voltage - Rated":"200VAC, 250VDC","Operating Temperature":"-55\u00b0C ~ 125\u00b0C","Shell Size, MIL":"-","Contact Finish Thickness":"-","Number of Positions":"24","Datasheets":"MS3102E24-28PW Drawing","Standard Package":"1","Family":"Circular Connectors","Shell Size - Insert":"24-28","Connector Type":"Receptacle, Male Pins","Contact Finish":"Silver","Fastening Type":"Threaded","Termination":"Solder Cup","Features":"-","Ingress Protection":"Env...
