{"Contact Classification":"26Signal","Strain Relief":"No","Family":"D38999","Voltage Rating":"850VDC/600VAC","Gender":"PL","Number of Terminals":"26","Product Height (mm)":"Not Required(mm)","Contact Gender":"SKT","Product Length (mm)":"31(mm)","Mounting Style":"Cable","Number of Ports":"1(Port)","Rad Hardened":"No","Product Depth (mm)":"Not Required(mm)","Product Diameter (mm)":"35.7(mm)","Termination Method":"Crimp","Operating Temp Range":"-65C to 175C","Shell Size / Insert Arrangement":"17-26","Number of...

{"Status":"ACTIVE","Body/Shell Style":"PLUG","MIL Conformance":"Yes","Total Number of Contacts":"26","Option":"GENERAL PURPOSE","Mounting Type":"CABLE","Contact Finish - Mating":"NOT SPECIFIED","Shell Finish":"CADMIUM PLATED","Backshell Type":"SOLID","Environmental Characteristics":"CORROSION/ENVIRONMENT/FLUID/VIBRATION RESISTANT","Contact Finish - Termination":"NOT SPECIFIED","Contact Gender":"FEMALE","Coupling Type":"THREADED","Shell Material":"ALUMINUM ALLOY","Manufacturer Series":"D38999/26","Empty Shel...

{"Mounting Angle":"Straight","Product Category":"Circular MIL Spec Connector","RoHS":"No","Tradename":"38999","Shell Material":"Aluminum","Series":"D38999 III","MIL Type":"MIL-DTL-38999 III","Shell Size":"17","Termination Style":"Crimp","Contact Gender":"Socket (Female)","Shell Style":"Straight","Brand":"Amphenol Aerospace","Insert Arrangement":"17-26","Contact Plating":"Gold","Mating Style":"Threaded","Part # Aliases":"88-565865-26J","Product Type":"Plugs","Number of Positions":"26 Position","Shell Plating...

{"Status":"ACTIVE","Body/Shell Style":"PLUG","MIL Conformance":"Yes","Total Number of Contacts":"26","Option":"GENERAL PURPOSE","Mounting Type":"CABLE","Contact Finish - Mating":"NOT SPECIFIED","Shell Finish":"CADMIUM PLATED","Backshell Type":"SOLID","Environmental Characteristics":"CORROSION/ENVIRONMENT/MOISTURE/VIBRATION RESISTANT","Contact Finish - Termination":"NOT SPECIFIED","Contact Gender":"FEMALE","Coupling Type":"THREADED","Shell Material":"ALUMINUM ALLOY","Manufacturer Series":"D38999/26","Empty S...

{"Connector Shell Size:":"17","Connector Mounting:":"Cable","Insert Arrangement:":"17-26","Product Range:":"MIL-C-38999 Series III","Gender:":"Plug","No. of Positions:":"26","Connector Type:":"Circular Military","Connector Body Material:":"Aluminium","SVHC:":"To Be Advised","Contact Gender:":"Socket"}...

{"Contact Classification":"26Signal","Type":"Circular","Current Rating (Max)":"7.5(A)","Product Height (mm)":"Not Required(mm)","Contact Plating":"Gold","Termination Method":"Crimp","Shell Size / Insert Arrangement":"17-26","Strain Relief":"No","Shell Plating":"Cadmium","Voltage Rating":"850VDC/600VAC","Gender":"PL","Body Orientation":"Straight","Contact Gender":"SKT","Number of Ports":"1(Port)","Operating Temp Range":"-65C to 175C","Product Diameter (mm)":"35.7(mm)","Family":"D38999","Number of Terminals":...

{"Category":"Connectors, Interconnects","Packaging":"Bulk","Contact Size":"20","Ingress Protection":"Environment Resistant","Mounting Type":"Free Hanging (In-Line)","Family":"Circular Connectors - Housings","Series":"Military, MIL-DTL-38999 Series III, KJB","Orientation":"B","Shell Size - Insert":"17-26","Connector Type":"Plug for Female Contacts","Shell Material, Finish":"Aluminum Alloy, Olive Drab Cadmium Plated","Note":"Contacts Not Provided","Datasheets":"D38999/26WE26BB Datasheet","Fastening Type":"Thr...

{"Status":"ACTIVE","Body/Shell Style":"PLUG","MIL Conformance":"Yes","Total Number of Contacts":"26","Option":"GENERAL PURPOSE","Mounting Type":"CABLE","Contact Finish - Mating":"NOT SPECIFIED","Shell Finish":"CADMIUM PLATED","Backshell Type":"SOLID","Environmental Characteristics":"FLUID RESISTANT","Contact Finish - Termination":"NOT SPECIFIED","Contact Gender":"FEMALE","Coupling Type":"THREADED","Shell Material":"ALUMINUM ALLOY","Manufacturer Series":"D38999/26","Empty Shell":"Yes","Shell Size":"E","Matin...

{"Category":"Connectors, Interconnects","Note":"Contacts Not Provided","Mounting Type":"Free Hanging (In-Line)","Shell Size, MIL":"E","Number of Positions":"26","Mating Products":"DD38999/20WE26PB-LC-ND - CONN HSG RCPT FLANGE 26POS PIN DD38999/20WE26AB-ND - CONN HSG RCPT FLANGE 26POS PIN DD38999/20WE26PB-ND - CONN RCPT 26POS FLANGE W/PINS DD38999/24WE26PB-LC-ND - CONN HSG RCPT JAM NUT 26POS PIN DD38999/24WE26AB-ND - CONN HSG RCPT JAM NUT 26POS PIN DD38999/24WE26PB-ND - CONN RCPT 26POS JAM NUT W/PINS","Datas...
