{"DC Resistance Max, Parallel:":"0.047 ohm","Packaging:":"Cut Tape","DC Current Rating:":"2.5 A","Inductance, Parallel:":"9.88 \u00b5H","Inductance Tolerance:":"\u00b1 20%","DC Resistance Max:":"0.03 ohm","Case Dimensions:":"11.43mm x 11.43mm x 6.35mm","RMS Current, Parallel:":"2.5 A","Product Range:":"ECONO-PAC 4P Series","No. of Pins:":"4","Saturation Current, Parallel:":"-","Inductance:":"9.88 \u00b5H","SVHC:":"To Be Advised","Core Material:":"Iron","Coupled Inductor Case:":"11.43mm x 11.43mm x 6.35mm","...

{"Terminal Finish":"NOT SPECIFIED","Inductance-Nom (L)":"9.88 uH","Operating Temperature-Max":"85 Cel","Tolerance":"20 %","Status":"ACTIVE","Lead Free":"Yes","Operating Temperature-Min":"-40 Cel","Core Material":"POWDERED IRON","Number of Functions":"2","Inductor Application":"POWER INDUCTOR","Shape/Size Description":"RECTANGULAR PACKAGE","DC Resistance":"0.0470 ohm","EU RoHS Compliant":"Yes","Terminal Placement":"ON CIRCLE","Rated Current-Max":"2.5 A","Terminal Shape":"ONE SURFACE","Manufacturer Series":"C...

{"Category":"Inductors, Coils, Chokes","Number of Coils":"2","Catalog Drawings":"CTX-(4,4P,4A) Series CTX-[3,4,(3,4)P,(3,4)A] Series Footprint Parallel Connection Pin Out Series Connection Pin Out Ratio Transformer Pin Out","Current":"1.25A","Package / Case":"Nonstandard","Tolerance":"\u00b120%","Packaging":"Tape & Reel (TR)","Shielding":"Unshielded","DC Resistance (DCR)":"93.5 mOhm Max","Product Photos":"CTX10-4P-R","PCN Assembly/Origin":"Multiple Devices 31/Aug/2013 Coiltronics Magnetics Facility 31/Aug/2...

{"Failure Rate":"Not Required","Packaging ":"Tape and Reel","Number of Terminals":"4","Military Standard":"Not Required","Technology":"Wirewound","Product Height (mm)":"6.35(mm)","Rad Hardened":"No","Test Frequency":"0.1(MHz)","Operating Temp Range":"-40C to 125C","Product Depth (mm)":"13.97(mm)","Product Diameter (mm)":"Not Required(mm)","Core Material":"Powdered Iron","Inductance":"9.88/39.53(uH)","Impedance":"Not Required ohm","Tolerance (+ or -)":"20%","Type":"Power","Product Length (mm)":"13.97(mm)","D...
