wise noted. 3. The specifications, characteristics and technical data described in the datasheet are subject to change without prior notice. SPEC NO: DSAH3815 REV NO: V.5 DATE: MAY/11/2011 PAGE: 1 OF 6 APPROVED: WYNEC CHECKED: Allen Liu DRAWN: J.Yu ERP: 1102013040 Selection Guide Part No. Dice WP7104ALUP/2SRD-0L Iv (mcd) [2] @ 20mA Lens Type Super Bright Red (GaAlAs) Viewing Angle [1] Min. Typ. 21/2 150 400 40 Red Diffused Notes: 1. 1/2 is the angle from optical centerline where the luminous intensity is 1/2 of the optical peak value. 2. Luminous intensity/ luminous Flux: +/-15%. Electrical / Optical Characteristics at TA=25C Symbol Parameter Device Typ. peak Peak Wavelength Super Bright Red D [1] Dominant Wavelength 1/2 Max. Units Test Conditions 660 nm IF=20mA Super Bright Red 640 nm IF=20mA Spectral Line Half-width Super Bright Red 20 nm IF=20mA C Capacitance Super Bright Red 45 pF VF=0V;f=1MHz VF [2] Forward Voltage Super Bright Red 1.85 2.5 V IF=20mA IR Reverse Current Super Bright Red 10 uA

se noted. 3. The specifications, characteristics and technical data described in the datasheet are subject to change without prior notice. SPEC NO: DSAH3815 REV NO: V.6A DATE: JAN/26/2013 PAGE: 1 OF 6 APPROVED: WYNEC CHECKED: Allen Liu DRAWN: F.Cui ERP: 1102013040 Selection Guide Part No. Dice WP7104ALUP/2SRD-0L Lens Type Super Bright Red (GaAlAs) Iv (mcd) [2] @ 20mA Viewing Angle [1] Min. Typ. 150 400 *50 *100 21/2 40 Red Diffused Notes: 1. 1/2 is the angle from optical centerline where the luminous intensity is 1/2 of the optical peak value. 2. Luminous intensity/ luminous Flux: +/-15%. * Luminous intensity value is traceable to the CIE127-2007 compliant national standards. Electrical / Optical Characteristics at TA=25C Symbol Parameter Device Typ. peak Peak Wavelength Super Bright Red D [1] Dominant Wavelength 1/2 Max. Units Test Conditions 655 nm IF=20mA Super Bright Red 640 nm IF=20mA Spectral Line Half-width Super Bright Red 20 nm IF=20mA C Capacitance Super Bright Red 45 pF VF=0V;f=1MHz VF

se noted. 3. The specifications, characteristics and technical data described in the datasheet are subject to change without prior notice. SPEC NO: DSAH3816 REV NO: V.7B DATE: JAN/26/2013 PAGE: 1 OF 6 APPROVED: WYNEC CHECKED: Allen Liu DRAWN: F.Cui ERP: 1102013041 Selection Guide Part No. Dice WP7104ALUP/2YD-0L Lens Type Yellow (GaAsP/GaP) Yellow Diffused Viewing Angle [1] Iv (mcd) [2] @ 10mA Min. Typ. 21/2 8 15 40 Notes: 1. 1/2 is the angle from optical centerline where the luminous intensity is 1/2 of the optical peak value. 2. Luminous intensity/ luminous Flux: +/-15%. 3. Luminous intensity value is traceable to the CIE127-2007 compliant national standards. Electrical / Optical Characteristics at TA=25C Symbol Parameter Device Typ. peak Peak Wavelength Yellow D [1] Dominant Wavelength 1/2 Max. Units Test Conditions 590 nm IF=20mA Yellow 588 nm IF=20mA Spectral Line Half-width Yellow 35 nm IF=20mA C Capacitance Yellow 20 pF VF=0V;f=1MHz VF [2] Forward Voltage Yellow 2.1 2.5 V IF=20mA IR Reverse

package. 4. The specifications, characteristics and technical data described in the datasheet are subject to change without prior notice. SPEC NO: DSAF1890 REV NO: V.4 DATE: NOV/12/2010 APPROVED: WYNEC CHECKED: Allen Liu DRAWN: C.H.Han PAGE: 1 OF 6 ERP: 1102013046 Selection Guide Part No. Dice WP934MD/2YD Lens Type Yellow (GaAsP/GaP) Yellow Diffused Viewing Angle [1] Iv (mcd) [2] @ 10mA Min. Typ. 21/2 8 15 40 Notes: 1. 1/2 is the angle from optical centerline where the luminous intensity is 1/2 of the optical peak value. 2. Luminous intensity/ luminous Flux: +/-15%. Electrical / Optical Characteristics at TA=25C Symbol Parameter Device Typ. peak Peak Wavelength Yellow D [1] Dominant Wavelength 1/2 Max. Units Test Conditions 590 nm IF=20mA Yellow 588 nm IF=20mA Spectral Line Half-width Yellow 35 nm IF=20mA C Capacitance Yellow 20 pF VF=0V;f=1MHz VF [2] Forward Voltage Yellow 2.1 2.5 V IF=20mA IR Reverse Current Yellow 10 uA VR = 5V Notes: 1.Wavelength: +/-1nm. 2. Forward Voltage: +/-0.1V. Absolute
